Intel Core I9-11900 11th Gen Processor 16M


Intel Core I9-11900 11th Gen Processor 16M-02

Descriptions :

  1. Model: Core i9-11900 11th Gen
  2. Clock Speed: 2.50 GHz Up to 5.20 GHz
  3. Cache: 16 MB, Socket: LGA 1200
  4. CPU Cores: 8, CPU Threads: 16
  5. GPU name: Intel UHD Graphics 750


Intel Core I9-11900 11th Gen Processor (16M Cache, Up To 5.20 GHz)

Intel Core I9-11900 11th Gen Processor 16M-03

Product Description

Intel 11th Gen Core i9-11900 Rocke Lake Processor

This Core i9-11900 Processor comes with Intel UHD Graphics 750. This new 11th word Rocket Lake microarchitecture is manufactured with the 14nm process that comes with eight cores and 16 vestments. As this chip is streamlined to the bottommost Biographies revision, it nicely fits into any Intel 400 and 500 series motherboards.

Fastening on this, all the major motherboard manufacturers have formerly started BIOS updates for their 400 and 500 series lineup. These Processors also support 64- bit computing on Intel architecture bear an Intel x86-64 (64 bitarchitecture– enabled Biographies.


  1. Model: Core i9-11900 11th Gen
  2. Clock Speed: 2.50 GHz Up to 5.20 GHz
  3. Cache: 16 MB, Socket: LGA 1200
  4. CPU Cores: 8, CPU Threads: 16
  5. GPU name: Intel UHD Graphics 750

Intel® Core™ i9-11900 Processor  (16M Cache- up to 5.20 GHz)

Product Collection11th Generation Intel® Core™ i9 Processors
Code NameProducts formerly Rocket Lake
Vertical SegmentDesktop
Processor Numberi9-11900
Launch DateQ1’21
Lithography14 nm
Use ConditionsPC/Client/Tablet

CPU Specifications

Total Cores8
Total Threads16
Max Turbo Frequency5.20 GHz
Intel® Thermal Velocity Boost Frequency5.20 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency ‡5.10 GHz
Intel® Turbo Boost Technology 2.0 Frequency‡5.00 GHz
Processor Base Frequency2.50 GHz
Cache16 MB Intel® Smart Cache
Bus Speed8 GT/s
Supplemental Information
Embedded Options AvailableNo
Memory Specifications
Max Memory Size (dependent on memory type)128 GB
Memory TypesDDR4-3200
Max # of Memory Channels2
Max Memory Bandwidth50 GB/s
ECC Memory Supported   ‡No

Processor Graphics

Processor Graphics ‡Intel® UHD Graphics 750
Graphics Base Frequency350 MHz
Graphics Max Dynamic Frequency1.30 GHz
Graphics Video Max Memory64 GB
Execution Units32
4K SupportYes |  at 60Hz
Max Resolution (HDMI)‡4096×2160@60Hz
Max Resolution (DP)‡5120 x 3200 @60Hz
Max Resolution (eDP – Integrated Flat Panel)‡5120 x 3200 @60Hz
DirectX* Support12.1
OpenGL* Support4.5
Intel® Quick Sync VideoYes
Intel® InTru™ 3D TechnologyYes
Intel® Clear Video HD TechnologyYes
Intel® Clear Video TechnologyYes
# of Displays Supported ‡3
Device ID0x4C8A
OpenCL* Support3

Expansion Options

Scalability1S Only
PCI Express Revision4
PCI Express Configurations ‡Up to 1×16+1×4 |  2×8+1×4 |  1×8+3×4
Max # of PCI Express Lanes20
Package Specifications
Sockets SupportedFCLGA1200
Max CPU Configuration1
Thermal Solution SpecificationPCG 2019C
Intel® Thermal Velocity Boost Temperature70 °C
Package Size37.5 mm x 37.5 mm

Advanced Technologies

Intel® Gaussian & Neural Accelerator2
Intel® Deep Learning Boost (Intel® DL Boost)Yes
Intel® Optane™ Memory Supported ‡Yes
Intel® Thermal Velocity BoostYes
Intel® Turbo Boost Max Technology 3.0 ‡Yes
Intel® Turbo Boost Technology ‡2
Intel vPro® Platform Eligibility ‡Yes
Intel® Hyper-Threading Technology ‡Yes
Intel® Virtualization Technology (VT-x) ‡Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡Yes
Intel® VT-x with Extended Page Tables (EPT) ‡Yes
Intel® 64 ‡Yes
Instruction Set64-bit
Instruction Set ExtensionsIntel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2 |  Intel® AVX-512
Idle StatesYes
Enhanced Intel SpeedStep® TechnologyYes
Thermal Monitoring TechnologiesYes
Intel® Identity Protection Technology ‡Yes
Intel® Stable Image Platform Program (SIPP)Yes

Security & Reliability

Intel® AES New InstructionsYes
Secure KeyYes
Intel® Software Guard Extensions (Intel® SGX)No
Intel® OS GuardYes
Intel® Trusted Execution Technology ‡Yes
Execute Disable Bit ‡Yes
Intel® Boot GuardYes
